Sw6206/Sw6208 Qc4 & Pd3.0 22.5W Power Bank Pcb – Front Led Status Indicators (Version C)

The SW6206 SW6208 QC4 PD3.0 22.5W Power Bank Module is an advanced fast-charging circuit board designed for DIY power banks, battery packs, and portable charging stations. It supports Quick Charge 4.0, Power Delivery 3.0, and other fast-charging protocols, ensuring high-speed and efficient power delivery to your devices.

Key Features

• Supports QC4.0, PD3.0, SCP, FCP, AFC, and other fast-charging protocols
• Power output: 22.5W max, ensuring rapid charging
• Compatible with USB-A and USB-C devices
• Input voltage: 5V/9V/12V, Output voltage: 5V/9V/12V/20V
• Integrated over-voltage, over-current, and short-circuit protection
• Ideal for DIY power banks, solar charging, and battery packs

Applications

• DIY power banks for smartphones, tablets, and USB devices
• Portable charging stations for travel and emergencies
• Solar energy storage systems with USB output
• Fast-charging circuits for IoT and embedded systems
• Battery backup systems for USB-powered gadgets

Related Products

• 18650 Battery Pack for Power Bank Modules
• USB-C Fast Charger for Quick Charging
• DIY Power Bank Case for Custom Battery Packs

Learn More

• SW6206: Datasheet

Frequently Asked Questions

Does this module support fast charging for iPhones and Android devices?

Yes, the SW6206 SW6208 module supports QC4.0 and PD3.0, making it compatible with fast charging for iPhones, Samsung, Xiaomi, and other devices.

Can I use this module with a solar panel?

Yes, you can integrate this module with solar panels that provide a stable DC voltage (5V-12V input) for off-grid charging solutions.

What type of batteries can I use with this power bank module?

This module is compatible with 18650 Li-ion batteries, lithium-polymer battery packs, and other DC power sources.

Package Includes

• 1 x SW6206 SW6208 QC4 PD3.0 22.5W Power Bank Module
