Description
DC-022 DC Power Jack PCB Mount Female Connector 3 Pin, 5.5mm x 2.1mm
The DC-022 DC Power Jack offers a high-quality PCB mount female connector, ensuring reliable performance in power supply applications. With a 5.5mm x 2.1mm barrel size and a 3-pin configuration, it guarantees a stable and secure connection for DC-powered devices. Additionally, its compact design allows for seamless integration into PCB projects and electronic equipment, making it an ideal choice for various applications.
Key Features
- 3-Pin PCB Mount: Ensures a secure and stable connection to printed circuit boards.
- 5.5mm x 2.1mm Barrel Size: Offers compatibility with standard DC power adapters for hassle-free integration.
- Durable Build: Features high-quality plastic and metal construction, providing long-lasting reliability.
- Compact and Lightweight: Allows for easy installation, making it perfect for small electronic devices.
- Without Nut: Designed specifically for PCB mounting, eliminating the need for an external nut.
- Wide Application: Works well with power adapters, DIY electronics, and embedded systems, ensuring versatile usage.
Specifications
| General | |
|---|---|
| Model Number | DC-022 |
| Connector Type | DC Power Jack (Female) |
| Mounting Type | PCB Mount |
| Number of Pins | 3 |
| Barrel Size | 5.5mm (Outer) x 2.1mm (Inner) |
| Material | Plastic & Metal |
| Nut Included | No |
| Application | Power Supply, PCB Circuits, DIY Projects |
Related Products
- 2.1×5.5mm Dc Jack Pcb Mount Internal Barrel Connector
- Pcb Mount Female Connector 3 Pin With Nut
- Pj-324 Pcb Mount Female Audio Connector
Learn More
- Female JST connector for PCB mount
- PCB Connectors Crash Course: All the Connectors You Should Know About
- Female PCB mount ATX connectors?
Related Video
Frequently Asked Questions (FAQ)
What is the size of the DC jack barrel?
First, the DC jack barrel has a 5.5mm outer diameter and 2.1mm inner diameter, making it fully compatible with standard power adapters.
Is this DC jack suitable for PCB mounting?
Yes, the DC-022 supports PCB mounting with a 3-pin design, allowing it to connect directly to the PCB for a secure and stable fit.
Does this power jack come with a nut?
No, this version does not include a nut, making it perfect for easy PCB integration without extra parts.
What applications is this power jack suitable for?
This power jack works well for power adapters, PCB circuits, DIY electronics, and embedded systems, offering reliable and versatile performance.
Package Includes
- 1 x DC-022 DC Power Jack PCB Mount Female Connector
